TORQEEDO DEEP BLUE 25 SAILDRIVE V 1.4 FOR SALE

Description TORQEEDO DEEP BLUE 25 SAILDRIVE V 1.4 FOR SALE The most powerful electric saildrive from serial production is a Torqeedo. The Deep Blue SD can propel displacement vessels weighing up to 50 tons as well as large yachts at speeds of up to 18 km/h. This makes cruising with large yachts completely emission–free with virtually no noise or vibration. The shaft–free design allows installation at almost any point and makes maintenance of the Deep Blue SD very convenient. Seamless integration with the Deep Blue Hybrid system offers the option of energy recovery while sailing. Deep Blue 25 SD – Benefits: Light weight (saildrive with motor and electronics system 190 lbs) Space-saving design Compatible with standard mounting flanges Best performance with maximum convenience Professional safety Range Deep Blue 25 SD with one high voltage battery   Speed in knots (km/h)* Range in nm (km)* Running time in hh:mm* Slow 5,0 (9,3) 12,5 (23,3) 02:30 Full throttle 10,0 (18,5) 5,0 (9,3) 0:30   * Depends on type of boat, load, propeller and conditions. Speed and range indications do not represent a legal guarantee. Information on range and speed For a displacement boat making way through the water, the required propulsive power increases in proportion to the cube of the speed. This means that if you want to double your speed, you need eight times as much power. And vice-versa, a small reduction in speed is enough to increase the achievable range substantially  The Torqeedo Deep Blue’s on-board computer calculates the remaining range constantly, by linking the motor’s consumption data with the charging level of the batteries, and the speed over the ground from the GPS. This allows you to read the remaining range in real time from the motor display or the smartphone app TorqTrac. Specifications Technical Data Deep Blue 25 SD Peak input power in kW 33 Input power (continuous) in kW 25 Propulsive power in kW 16.2 Comparable petrol outboard (shaft power) 40 HP Maximum overall efficiency in % 54 Integrated battery: usable energy in kWh 12.8 Nominal voltage 345 Final charging voltage 389 Motor weight including electronics (without battery) in kg 86 Weight of 1 battery in kg 149 Total system weight in kg – example (sail drive, 1 charger, System Management Unit, display, throttle and cabling) 314 Shaft length 36.2 cm Standard propeller – Maximum propeller speed in rpm at full load 1,200 Control Remote throttle Tilting device – Trim device – Integrated on-board computer with touch-screen display Yes   Product description Saildrive drive system with 25 kW shaft power Complete system consisting of: Saildrive System management unit On-board computer with display High-voltage battery Charger Remote throttle Wiring Item number: 3401-00  | EAN: 4260113694183 Deep Blue 25 SD The most powerful electric saildrive from serial production is a Torqeedo. The Deep Blue SD can propel displacement vessels weighing up to 50 tons as well as large yachts at speeds of up to 18 km/h. This makes cruising with large yachts completely emission-free with virtually no noise or vibration. The shaft-free design allows installation at almost any point and makes maintenance of the Deep Blue SD very convenient. Seamless integration with the Deep Blue Hybrid system offers the option of energy recovery while sailing. Deep Blue 25 SD – Benefits: Light weight (saildrive with motor and electronics system 190 lbs) Space-saving design Compatible with standard mounting flanges Standards-compliant seamless overall system Best performance with maximum convenience Professional safety Electronically commutated brushless motor with outstanding efficiency (98% motor efficiency) Range Deep Blue 25 SD with one high voltage battery Speed in knots (km/h)* Range in nm (km)* Running time in hours: minutes Slow 5,0 (9,3) 12,5 (23,3) 02:30 Full throttle 10,0 (18,5) 5,0 (9,3) 00:30 * Depends on type of boat, load, propeller and conditions. Speed and range indications do not represent a legal guarantee. Information on range and speed For a displacement boat making way through the water, the required propulsive power increases in proportion to the cube of the speed. This means that if you want to double your speed, you need eight times as much power. And vice-versa, a small reduction in speed is enough to increase the achievable range substantially. The Torqeedo Deep Blue’s on-board computer calculates the remaining range constantly, by linking the motor’s consumption data with the charging level of the batteries, and the speed over the ground from the GPS. This allows you to read the remaining range in real time from the motor display or the smartphone app TorqTrac. Specifications Technical Data Deep Blue 25 SD   Deep Blue 25 SD Input power (continuous) in kW 25 Propulsive power in kW 16.2 Comparable petrol outboard (shaft power) 40 HP Motor weight including electronics in kg 125 Shaft length 36.2 cm Maximum propeller speed in rpm at full load 1,360   Torqeedo YouTube Channel TORQEEDO DEEP BLUE 25 SAILDRIVE V 1.4 FOR SALE,TORQEEDO DEEP BLUE 25 SAILDRIVE V 1.4 FOR SALE,TORQEEDO DEEP BLUE 25 SAILDRIVE V 1.4 FOR SALE,TORQEEDO DEEP BLUE 25 SAILDRIVE V 1.4 FOR SALE,TORQEEDO DEEP BLUE 25 SAILDRIVE V 1.4 FOR SALE,TORQEEDO DEEP BLUE 25 SAILDRIVE V 1.4 FOR SALE,TORQEEDO DEEP BLUE 25 SAILDRIVE V 1.4 FOR SALE,TORQEEDO DEEP BLUE 25 SAILDRIVE V 1.4 FOR SALE,TORQEEDO DEEP BLUE 25 SAILDRIVE V 1.4 FOR SALE,TORQEEDO DEEP BLUE 25 SAILDRIVE V 1.4 FOR SALE,
